Tokyo Hy-Power HL-120U
| Type: |
UHF all-mode Linear Amplifier |
| Frequency Range: |
430-450 MHz (70 cm) |
| Voltage: |
13.8 VDC |
| Current Drain: |
Max 17 A |
| Drive power: |
1-4 W |
| Maximum output power: |
FM/SSB/CW: Max 100 W
ATV (AM video): Max 60 W |
| Dimensions (W*H*D): |
218 x 82 x 300 mm (8.58 x 3.23 x 11.81 inches) |
| Weight: |
3.5 Kg (7.72 lb) |
| Manufactured: |
Japan: 19xx-19xx |
| Other: |
Built-in GaAsFET Preamp |
| Related Documents: |
User Manual (633 kb) |
 |
